ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082*, - Impedance sense for front and rear headphone outputs, - Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking, - High quality 120 dB SNR stereo playback output and 110 dB SNR recording input, - Supports up to 32-Bit/384 kHz playback on front panel, Audio Features, - SupremeFX Shielding Technology, - ESS ® ES9219 QUAD DAC, - LED-illuminated audio jacks, - Rear optical S/PDIF out port, - Premium audio capacitors, * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output., ** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
Caracteristici speciale
Supports up to 5 x M.2 slots and 1 x SlimSAS connector and 4 x SATA 6Gb/s ports*, AMD Ryzen™ 9000 & 7000 Series Desktop Processors, M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode), M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**, M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)**, AMD Ryzen™ 8000 Series Desktop Processors, M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode), M.2_2 slot (Key M), type 2242/2260/2280 (Not supports), M.2_3 slot (Key M), type 2242/2260/2280/22110 (Not supports), AMD X870E Chipset, DIMM.2_1 slot (Key M) via ROG Q-DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode), DIMM.2_2 slot (Key M) via ROG Q-DIMM.2, type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode), SlimSAS connector supports PCIe 4.0 x4 mode via an SFF-8654 adapter cable. The cable is purchased separately., 4 x SATA 6Gb/s ports, * Specifications vary by CPU types., ** When M.2_2 is ena
-Nicio recenzie încă
Părerea ta contează. Recenziile pot fi lăsate doar de clienții care au achiziționat acest produs, după finalizarea comenzii - astfel, fiecare evaluare reflectă o experiență reală de cumpărare.Autentifică-te în contul tău pentru a-ți împărtăși experiența și a-i ajuta pe ceilalți cumpărători să aleagă în cunoștință de cauză.
Nu există recenzii încă. Fii primul care lasă o părere!
1 × Port HDMI, 2 × Porturi USB4 (40 Gbps) acceptă ieșiri display USB Tip-C, * Specificațiile graficii pot varia în funcție de tipurile de CPU. Consultați specificațiile CPU AMD., ** Acceptă 4K@60Hz conform specificațiilor HDMI 2.1., *** Acceptă max. 4K@60Hz conform specificațiilor DisplayPort 1.4a, **** Suportul rezoluției VGA depinde de rezoluția procesoarelor sau plăcilor grafice.
