Cameră pentru documente DAHUA DHI-PKP-KB0A, Black | dabstore.ro

Cameră

Photographing Area

A4

Focus Mode

AF auto focus

Auto adjustment

Mod de compensare a culorii

Auto adjustment

Imaging Distance

150 mm–260 mm

Total Pixels

13 MP

Effective Pixels

13 MP

Format ieșire video

MJPG, YUV2 (third-party software)

Rată max. de cadre la ieșire

4168 × 3126/10 fps

Sursă de alimentare

USB

Tensiune

5 VDC

Lens Distortion

Rezoluție de ieșire implicită

4168 × 3126

Rezoluții de ieșire suportate

MJPG format resolution: 4168 × 3126, 4160 × 3120, 3840 × 2160, 3264 × 2448, 2592 × 1944, 2048 × 1536, 1920 × 1080, 1600 × 1200, 1280 × 720, 1024 × 768, 640 × 480 YUY2 format resolution: 1920 × 1080, 1600 × 1200, 1280 × 720, 1024 × 768, 800 × 600, 640 × 480

Porturi dispozitiv

Port USB

1 × USB-A (USB 2.0)

Function

Illuminator

5 adjustable brightness levels

Gestures

Supports moving images with your fingers, scaling with 2 fingers and erasing with the swiping gesture.

Annotation

6 selectable colors

Eraser

3 eraser sizes and one-click clear page

Rotation

Supports rotating the screen 90 degrees with one click.


Images are automatically optimized after switching to the AI photo function (the tablet device should be connected to the booth)

Album

The images will be automatically saved to the album when AI photo is turned on. You can click any of the images to view and rotate them, make annotations, and more. Import the images from OPS to the album in the whiteboard. It supports saving annotated images and performing split screen (6 windows), which helps with making comparisons during teaching. You can also erase annotations, use full screen view, zoom in and out, rotate images, save, and replace images.

Tools

Supports zooming in and out of images, and adjusting their brightness, contrast and saturation. Settings: 1. Frames Tab: Supports enabling and disabling panoramic mode, motion, HDV and screen lock. 2. Photo Tab: Supports enabling and disabling AI photo, smart photo, comparison, and burst mode. Burst mode has 3 options: smart, 5 sec and 10 sec. 3. Routine Tab: Supports enabling and disabling device model, resolution, and tips, and selecting the toolbar (bottom/2 sides), focus (lock/auto), and language (Chinese/English). Device information can also be displayed.

Aerial View

Supports displaying images on the whiteboard and navigating within large images.

Minimization

Windows can be minimized.

Curent

Putere consumată

≤2.5 W

Consum de energie în standby

≤0.25 W

Temperatură de funcționare

–15 °C to +45 °C

Temperatură de depozitare

–20 °C to +60 °C

Umiditate de operare

0%–93%, 101 KPa

Umiditate depozitare

0%–95%, 101 KPa

Dimensiuni produs

When open, 388 mm × 385 mm × 270 mm / 15.28 inch × 15.16 inch × 10.63 inch; When closed, 380 mm × 70 mm × 270 mm / 14.96 inch × 2.76 inch × 10.63 inch

Dimensiuni ambalaj

326 mm × 105 mm × 454 mm / 12.83 inch × 4.13 inch × 17.87 inch

Greutate netă

1.45 kg

Greutate brută

3.9 kg–4.1 kg

Installation Method

Wall mount

Packing List

4 × expansion glue plugs, 4 × expansion bolts, 1 × USB connection cable, 1 × video booth, 1 × quality certificate, 1 × cable cover, 1 × wall-mount box, 2 × cable cover screws, 4 × PE wall-mounted bracket screws, 2 × glue plugs, 2 × keys
