Cameră speed dome de exterior DAHUA SD22204DB-GC, AHD / HD-CVI / HD-TVI / PAL, 1080p, obiectiv 2,7-11 mm | dabstore.ro

Cameră

Senzor de imagine

1/2.8 inch CMOS

Pixel

2 MP

Rezoluție maximă

1920 (H) × 1080 (V)

Electronic Shutter Speed

1/3 s–1/30,000 s

Scanning System

Progressive

Min. Illumination

0.005lux@F1.6 (Color, 30 IRE); 0.0005lux@F1.6 (B/W, 30 IRE)

S/N Ratio

≥50 dB

Caracteristici

ROM

128 MB

RAM

256 MB

Obiectiv

Distanță focală

2.7 mm–11 mm

Max. Aperture

F1.6–F3.0

Field of View

H: 99.1°–31.9° V: 53.4°–18.0° D: 117.7°–36.6°

Zoom optic

4×

Focus Control

Auto; semi-auto; manual

Close Focus Distance

1 m

Distanță DORI

Detect Observe Recognize Identify

151.7 m (497.70 ft)

59.9 m 30.3 m 15.2 m

PTZ

Pan/Tilt Range

Pan: 0° până la 355°; Tilt: 0° până la +90° (When the vertical field of view is between 0° and 10°, the device case will block part of the image)

Manual Control Speed

Pan: 0.1°–100°/s Tilt: 0.1°–60°/s

Preset Speed

Pan: 100°/s; Tilt: 60°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Power-off Memory

Idle Motion

Preset; Tour

PTZ Protocol

DH-SD Pelco-P/D (Auto recognition)

Video

Rezoluție

1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480)

Video Frame Rate

1080p (25/30 fps); 720p (25/30/50/60 fps)

Day/Night

BLC

WDR

DWDR

HLC

Echilibru alb

Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp

Gain Control

Auto/Manual

Reducere zgomot

2D NR; 3D NR

Defog

Electronic

Zoom digital

16×

Image Rotation

180°

Function

CVI Product Output Mode

TVI;CVI;CVBS;AHD (CVBS is only used for debugging)

Certificare

Certifications

CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpart B, ANSI C63.4-2014 UL: UL60950-1+CAN/CSA C22.2, No.60950-1

Port

Analog Output

1 channel (CVBS/CVI output, BNC)

RS-485

1 (baud rate range: 1200 bps–9600 bps)

Putere

Sursă de alimentare

12VDC, 1.5 A ± 10%

Putere consumată

Basic: 7 W Max.: 9 W (PTZ)

Environment

Temperatură de funcționare

–30 °C to +60 °C

Umiditate de operare

≤95% (RH)

Protecție

IP66; IK10; TVS 6000V lightning proof; surge protection; voltage transient protection

Structură

Dimensiuni produs

88.9 mm × Φ122.0 mm / 3.50 inch × Φ4.80 inch

Greutate netă

0.6 kg

Greutate brută

0.65 kg
